Research Paper Volume 10, Issue 12 pp 3745—3760

TAp73 regulates ATP7A: possible implications for ageing-related diseases

Figure 4. ATP7A expression affect lung cancer patient’s outcome. Overall survival analysis of lung cancer datasets (see Material and Methods for full list) relative to (a) Tp73 expression (232546_at probe, mean expression) (n=1926), (b) ATP7A expression (205198_s_at probe, mean expression) (n=1145), (c) Tp73 and ATP7A probes mean expression (n=1145). HGU133A probe set. Patients splitted by median. P values showed on the top. Overall survival analysis of lung cancer datasets relative to ATP7A expression (205198_s_at probe, mean expression) obtained filtering the results with (d) ”Adenocarcinoma” (n=673) and (e) “squamous cell carcinoma” histology type (n=271). HGU133A probe set. Patients split by median. P values showed on the top.
