# Shear Power Spectrum Reconstruction using Pseudo-Spectrum Method

###### Abstract

We develop a pseudo power spectrum technique for measuring the lensing power spectrum from weak lensing surveys in both the full sky and flat sky limits. The power spectrum approaches have a number of advantages over the traditional correlation function approach. We test the pseudo spectrum method by using numerical simulations with square-shape boundary that include masked regions with complex configuration due to bright stars and saturated spikes. Even when 25% of total area of the survey is masked, the method recovers the -mode power spectrum at a sub-percent precision over a wide range of multipoles

###### keywords:

cosmology: theory — gravitational lensing — large-scale structure of universe## 1 Introduction

Large scale structure deflects light rays as they propagate from
distant galaxies to us, thus distorting the shapes of these galaxies
(e.g., Bartelmann & Schneider, 2001; Hoekstra & Jain, 2008, for thorough reviews). This weak
lensing or cosmic shear signals measures a combination of the total
matter distribution projected along the line-of-sight and the angular
diameter distance. Since the first measurements of weak lensing only a
decade ago (Van Waerbeke et al., 2000; Wittman et al., 2000; Bacon, Refregier & Ellis, 2000; Kaiser, Wilson & Luppino, 2000), there have been
major improvements as surveys continue to grow in size and depth
(e.g. Fu et al., 2008; Ichiki, Takada & Takahashi, 2009; Schrabback et al., 2010, for the latest
results). Gravitational lensing is one
of the most promising methods of constraining cosmology including the
nature of dark energy (e.g. Takada & Bridle, 2007). There are various
on-going and planned surveys aimed at studying dark energy through the
high-precision weak lensing measurements: the CFHT Legacy
Survey^{1}^{1}1http://www.cfht.hawaii.edu/Science/CFHLS/, the Hyper
Suprime-Cam Weak Lensing Survey (Miyazaki et al., 2006), the Dark Energy
Survey (DES)^{2}^{2}2http://www.darkenergysurvey.org, and ultimately
Large Synoptic Survey Telescope (LSST)^{3}^{3}3http://www.lsst.org,
Euclid (Refregier et al., 2010), and Joint Dark Energy Mission (JDEM).

How should we analyze these new lensing data set? Most researchers use the two-point correlation function to characterize the cosmic shear signals. The correlation function method can be easily applied to complex survey geometries involving partial sky coverage and masked regions. However, the errors in the measurement are highly correlated between different bins (see Schneider et al., 2002; Joachimi, Schneider & Efler, 2008, for the detailed studies). Even if the shear field follows Gaussian statistics, which is a good approximation in the linear regime, there are large correlations between different angular-scale bins. These correlations are even larger, and more model-dependent on the smaller scales that contain most of the current observational information. Since the accurate estimate of the covariances is essential for robust cosmological constraints, a large number of numerical simulations are necessary (Semboloni et al., 2007).

The power spectrum, the Fourier- or Harmonic-transformed counterpart of the two-point correlation function, is an alternative means of measuring the cosmic shear correlations. Whilst the correlation function and power spectrum are mathematically equivalent, the power spectrum measurement of cosmic shear has been used less (see the COMBO 17-survey by Brown et al., 2003). The power spectrum approach has a number of advantages: its theoretical interpretation is simpler and there are weaker correlations between band powers at different multipoles. For example, the different bins are independent for the Gaussian field or on large angular scales. Even for small angular scales affected by nonlinear structure formation, the power spectrum covariances are relatively well understood through both analytical models and simulations of nonlinear structure formation (Hu & White, 2001; Cooray & Hu, 2001; Takada & Jain, 2009; Sato et al., 2009; Pielorz et al., 2009). The disadvantage is the presence of finite sky coverage and masked regions, which breaks the orthogonality of Fourier/Harmonic components. One needs to properly deal with the survey geometry effect to estimate unbiased power spectrum.

The purpose of this paper is to eliminate this disadvantage. We
employ the pseudo power spectrum technique, which is well
developed in the CMB studies (e.g. Wandelt, Hivon & Gorski, 2001) ^{4}^{4}4See
Seljak (1998) and Hu & White (2001) for the maximum likelihood
method of shear power spectrum estimation.. For the first time, we
apply the method to recover the lensing power spectrum from the shear
field taking into account incomplete survey geometry. To assess the
performance of this method, we make simulated shear maps including a
realistic configuration of masked regions due to bright stars and
saturated spikes. Furthermore, we develop the method for both the
full-sky and flat-sky approaches. The full-sky approach is adequate
for reconstructing large angular-scale modes that are relevant for the
curvature of the sky. On the other hand, the flat-sky approach should
serve as a practically useful approximation of sub-degree scale modes,
which carry most of useful cosmological information in the shear power
spectrum. We find that the pseudo power spectrum method allows for an
unbiased estimate of the underlying -mode power spectrum over a
range of angular scales we study. We also show that the residual
-mode power spectrum, which is leaked from -mode power due to an
imperfect reconstruction, can be well suppressed. Our method can be
applied to the existing data and forthcoming weak lensing surveys.

The paper is organized as follows: Section 2 describes the pseudo spectrum method to deconvolve shear power spectra with inhomogeneous survey mask. Section 3 describes the simulation maps we use to test the deconvolution method. We employ two different simulation maps: one is Gaussian shear maps and the other is the ray-tracing simulations of shear maps including the non-Gaussian effects due to nonlinear structure formation. Section 4 shows the results of both the full-sky and flat-sky approaches. Section 5 is devoted to the summary and conclusions.

## 2 Methodology: Reconstruction of Shear Power Spectrum

In this section we briefly review a method for reconstructing shear power spectra from the pseudo-spectrum estimators. We take into account an imperfect survey geometry due to survey boundary and masking effect. The method is analogous to the one used in estimating CMB polarization power spectra (Kogut et al., 2003; Brown, Castro & Taylor, 2005).

### 2.1 Full Sky Formalism

Since the shear field is a spin-2 field, the - and -mode harmonic coefficients of the shear fields can be expressed in the spherical harmonic expansion as

(1) |

and the inverse relation is

(2) |

where is the spin-2 spherical harmonics, and denotes the unit vector specifying the angular direction on the sky. The integration range is over the full sky.

In the linear regime, the statistical information in the map is fully encoded in the power spectra

(3) | |||||

(4) | |||||

(5) |

In the single lens limit, the shear field arising from a scalar gravitational field should be a gradient or curl-free field (). The multiple lensing effect generates B-mode power spectrum, but their power is times smaller than the E-mode power. Thus the -mode power spectrum effectively contains all information on the cosmic shear, i.e. -mode power spectrum is equivalent to that of the projected mass density along the line-of-sight between source galaxies and an observer. Hence the -mode can be used as a monitor of residual systematic effects. The standard methods to separate mode correlation functions involve integrals of the measured correlation functions down to arbitrary small scale or up to very large scale. As the scale range accessible from a finite sky data is limited, residual uncertainties are generated (Schneider et al., 1998; Crittenden et al., 2002, also see Schneider, Eifler & Krause 2010 for a new method using the limited-range integration of correlation function to separate the -mode).

Observational effects, such as a finite sky coverage and bright star masks, limit the survey area to a region . The observed shear field is modified as

(6) |

Without weighting, if the position vector lies in masked regions or regions outside the survey, otherwise within the survey. This finite sky coverage couples modes and generate artificial modes. We can describe the observed shear fields in terms of “pseudo E and B modes”, denoted as and

(7) |

These pseudo E and B modes are related to the true E and B modes as

(8) |

through a convolution kernel,

(9) | |||||

where

(10) |

The pseudo power spectra and are defined similarly to the equations (3)-(5) using pseudo and modes (eq.[8]). After straightforward algebraic calculation, one can find that the pseudo and true spectra are related to each other via

(11) |

where we have introduced the vector notations and so on for notational simplicity, and is the pixel window function. In the above equation we include the shot noise contribution arising from the intrinsic ellipticities of source galaxies. The intrinsic noise is simply modeled as the convolved noise power spectrum with the pixel window and the mask. Non-zero components of the mode-mode coupling matrix are given as

(12) | |||||

(13) | |||||

with being defined as

(15) |

Note that . Equation (11) tells that an imperfect survey geometry causes mode-mixing or equivalently a leakage of -mode power into the -mode even if .

The underlying power spectra can be reconstructed by solving the equation (11) inversely. The resolution in multipole space is limited by the survey area, i.e. the finer binning less than does not improve the statistical significance of the power spectrum reconstruction. Since the lensing power spectrum does not have fine scale structures in multipole space, such a coarse binning is sufficient to capture the shape of shear power spectrum. Also the coarse binning significantly reduces the computational cost of measuring the power spectrum in a wide range of multipoles. We therefore measure the binned power spectra defined as

(16) |

where the index “” denotes the -th multipole bin, and represents the summation over between and . Here we use a binned operator so that the binned power becomes the average of dimensionless power over between to

(17) |

The deconvolved binned spectrum is obtained as

(18) |

The mode mixing matrix for the binned spectra is

(19) |

where is the reciprocal of

(20) |

The equation (18) is the key equation for reconstructing the shear power spectra from masked shear maps in the full-sky approach in Section 4.

### 2.2 Flat-Sky Approximation

In this subsection, we present a formalism of a pseudo-spectrum method in the flat-sky approximation. The flat-sky approximation is enough applicable to current lensing survey, such as the CFHT survey covering a sky of about 200 square degrees in its 4 survey regions (e.g. Fu et al., 2008).

In the flat-sky approximation, and modes are defined as

(21) |

and inversely related as

(22) |

where the vector is a flat-space two-dimensional vector that approximates the three-dimensional vector in Eq. (1) around some reference point; e.g., if the coordinate origin in flat space is taken as the north pole, the position vector of an arbitrary point in the vicinity of the north pole is specified by two-dimensional vector . The vector is the corresponding wavenumber in the flat-space coordinate, and is defined as .

Like in the full-sky formalism, we again define pseudo E and B modes in a flat-sky limit as

(23) |

where represents an arbitrary mask field. We take into account the mask effect in two steps: a square boundary covering observed survey regions and the mask inside the square. Even for a complex survey geometry, such a square shape geometry can be obtained by using the zero-padding method such that the square-shape region encloses the whole region of data.

The pseudo -mode coefficient for a square field of a side length relate to the underlying true coefficients as (Bunn, 2002)

(24) |

where is the Fourier transform of the survey window function defined as

(25) |

and are -components of . The window function approaches as goes to .

The shear power spectra in flat-sky approximation is defined as

(26) |

Here is the two-dimensional Dirac delta function. From Eq. (24) the pseudo power spectra for the square area relate to the true one as

where and is the power spectrum of defined as

(28) |

The pseudo spectrum in the equation (LABEL:eq:flat_pseudo) depend on wavevector rather than its length. We later introduce the azimuthal angle average over in reconstructing the true spectra that depend only on the length of wavevector .

Although the relations between the pseudo and underlying spectra involve an infinite-range integral, we find that the equation (LABEL:eq:flat_pseudo) can be approximated by the following algebraical relations via the mode-mixing matrix:

(29) |

Non-zero components of the mode-mixing matrix are given using the power spectrum of the power spectrum of survey window (eq.[28]) as

(30) |

where

Note as in the full-sky approach. Since the discrete Fourier decomposition is limited by the resolution of survey size , we approximate the mode-mixing matrix as an average of the survey window function multiplied with either of or over a single pixel of area around the vector in Fourier space. The mode-mixing due to the survey window is important particularly for large-scale modes ().

We further need to include the masking effect inside the square boundary. As in the full-sky approach, the Fourier coefficients of the shear field with the inside mask is related to those without the mask as

(32) |

where the convolution kernel is given in terms of the Fourier transform of the mask function, , as

(33) |

In the equation (32) we use the discrete summation, rather than the infinite-range Fourier transform. The summation runs over the Fourier-space grids where the resolution of each grid is specified by the square size as . The number of grids, , needs to be specified by an observer to achieve the desired coverage of multipole range.

The pseudo spectra for the masked field inside the square boundary is

(34) |

The mode-coupling matrix for the masking effect is given by

(35) | |||||

(36) | |||||

(37) |

where is the power spectrum of the mask field inside the square boundary

(38) |

Combining the equations (29) and (34), the pseudo spectra is related to the true underlying spectra as

(39) |

We compute the binned power spectra:

(40) |

where the summation corresponds to an azimuthal angle average of , and runs over all the Fourier modes satisfying the condition . The operator is defined to average dimensionless power within the bin of scales

(41) |

and its reciprocal is

(42) |

The quantity is the number of Fourier modes available for the -th multipole bin, and is approximately given for a mode of as

(43) |

Therefore, as in the full-sky approach, the underlying power spectra can be estimated by deconvolving the pseudo power spectra in the flat-sky approximation:

(44) |

where the mode mixing matrix is given as

(45) |

with

(46) |

We use the equation (44) to reconstruct the power spectra from the pseudo spectra in the flat-sky approximation.

## 3 Simulations of Shear Maps

We use simulated maps of shear fields to test the pseudo-spectrum technique for reconstructing the shear power spectrum. We address how the method works for the case of lensing maps, where the lensing power spectrum has distinct shapes from the CMB power spectrum: the lensing spectrum has greater amplitudes at smaller scales. We also study the validity of the flat-sky approximation for recovering the input power spectrum down to very small angular scales in the presence of the finite-sky survey and masking effects.

### 3.1 Simulating the Lensed Sky

We construct two types of simulated shear fields: flat-sky non-Gaussian fields from ray-tracing simulations to test the flat-sky method and full-sky Gaussian fields to test the full-sky deconvolution method.

#### 3.1.1 Full Simulations in Flat-Sky Limit

We use the shear maps constructed from ray-tracing simulations developed by Sato et al. (2009) and test the flat-sky deconvolution method. The ray-tracing simulations are performed by placing N-body simulation boxes with two different sizes (240Mpc and 480Mpc at a side length) to cover a light cone of angular size from =0 to 3.5. The N-body simulations are based on the parallel Tree-Particle Mesh code Gadget-2 (Springel, 2005). The ray-tracing simulation follows the standard multiple lens plane algorithm (Jain, Seljak & White, 2000; Hamana & Mellier, 2001): separating the comoving distance between an observer and a source by fixed intervals of 120Mpc, computing the projected density contrast at each lens plane along the line-of-sight, we obtain the two-dimensional gravitational potential field related to the density contrast via Poisson equation. In this paper we use the simulations with a single source redshift . The initial ray directions are set on 2048 2048 Cartesian grids (resolution [arcmin]) and the ray positions at each lens plane are traced backward to the source plane via the lens equation. We obtain the shear field from the Jacobian matrix describing deformation of an infinitesimal light ray bundle. It should be noted that the obtained shear field does not obey the periodic boundary condition due to the projection to a single observer point through the different simulation boxes. The fundamental mode of the shear field is given by with . We use 1000 realizations of the shear maps in order to sufficiently reduce statistical scatters in the measured power spectra.

We adopt the concordance CDM model: the present-day density parameters of matter, cosmological constant, and baryon are , , and , respectively; the Hubble parameter ; the spectral index ; the rms density fluctuations in a sphere of 8Mpc radius used for the power spectrum normalization (Spergel et al., 2007).

#### 3.1.2 Gaussian Simulations in Full-Sky Limit

To test the full-sky formalism (Sec. 2.1), we construct Gaussian shear fields using the HEALPix software (Grski et al., 2005). We assume the survey geometry to be a rectangular shape covering 2000 square degree (see the top panel of Fig. 1). The resolution parameter of HEALPix pixelization is set to be 1024 corresponding to arcmin for the pixel scale and the maximum multipole .

The spectrum of the shear fields is of -mode only assuming the concordance cosmological model same as the N-body simulations (Sec. 3.1.1). In the weak lensing limit, the -mode shear power spectrum is equivalent to the power spectrum of lensing convergence field, the weighted mass density field projected between source galaxies and an observer along the line-of-sight. Assuming the Limber’s approximation (Limber, 1954), the -mode power spectrum is simply expressed as a weighted projection of the the matter power spectrum (k):

(47) |

where is the comoving angular diameter distance, and we throughout this paper assume a flat universe. Note that the comoving distance is given as a function of redshift, i.e. the distance-redshift relation . The lensing efficiency function, , is given by

(48) |

where is the normalized source distribution and

(49) |

with .

### 3.2 Simulating Realistic Masks

We consider three types of masks typical for ground-based imaging data analyses: point sources, saturation spikes, and bad pixels. First masked regions have circular shapes to model “bright stars” that are randomly distributed in the shear map. The radii of the bright star masks are randomly chosen ranging from 0.2 to 2 arcminutes. When the radius of the circle is greater than 1 arcmin, we add a rectangular-shape mask to model “saturation spikes” around a bright star. The mask has the size of ( is the radius of masked circle) with the same center as the circle. The different masked regions are allowed to be overlapped. We also mask all the pixels in a -direction row randomly selected with 5% probability. About 25% fraction of the area is totally masked in each simulation realization, which is typical for a ground-based imaging survey such as the Subaru Telescope (Hamana et al., 2003). The configuration of masked regions is demonstrated in the bottom panel of Fig. 1.

Since the pixel size of the ray-tracing simulations (0.15 arcmin) is smaller than the bright star mask, the mask function is set as when the center of the pixel is masked, otherwise 1. The middle panel of Fig. 1 shows a typical configuration of the simulated map with mask, while the spatial resolution is degraded in the plot. On the other hand, the Gaussian simulations have a large pixel size (4 arcmin) compared to the bright star mask, the mask function has a fractional value. Besides this difference the masking configuration is kept same in all the realizations for both the full-sky and flat-sky simulations.

### 3.3 Intrinsic Ellipticities

The intrinsic ellipticities of source galaxy shapes generate a white noise contamination to the power spectrum measurement assuming random orientations between different galaxies:

(50) |

where is the rms ellipticities per component and is the mean number density of source galaxies. In the following we assume and arcmin.

After masking the simulated shear fields, we add a Gaussian random noise with the variance of to each pixel, where is the pixel size. For Gaussian simulations, we add a effective noise with the variance of to pixels inside the survey area, where denotes the unmasked fraction roughly equal to 0.75.

## 4 Results

### 4.1 Power Spectrum Reconstruction

Fig. 2 shows the results of the shear spectrum reconstruction in the flat-sky approximation using 1000 realizations of the ray-tracing simulation. The left panel shows the noiseless results, while the right panel shows the results with intrinsic ellipticity. The shot noise spectra are subtracted from the measured spectra using the theoretical prediction (Eq. [50])) in this plot. In reality the shot noise spectra can be estimated by erasing the coherent cosmic shear signals in each galaxy shape, e.g. by remeasuring the shear spectra after randomly rotating orientations of each galaxy.

Middle panels in Fig. 2 plot the -mode power spectrum. The solid curve denotes the input power spectrum, while the dashed curve is the convolved spectrum, i.e. the measured power spectrum from the simulated shear maps without correcting for the survey geometry effect. The convolved spectrum systematically underestimates the underlying amplitudes over all the scales. On angular scales larger than a typical scale of masked areas (small ), the amplitude offset is roughly determined by the square of the masked area fraction i.e. . On the other hand, the offset on larger is given by the area fraction, . The modes, which angular scale is larger than the mask size, is fractionally affected by the mask and thus the amplitude decreases proportional to the masked fraction. Their power is thereby proportional to the square of the unmasked fraction. On the other hand, when the scale of modes is mush smaller than the mask size, their amplitude is 0 in masked region or 1 in unmasked region. As a result, their square value also has a value of 0 or 1 and thus the power is proportional just to the unmasked fraction (not the square).

The triangle symbols show the mean pseudo power spectra over 1000 realizations of the shear maps and the circle symbols are the deconvolved one. The error-bars represent the expected statistical errors of the band powers for a 2000 square degree survey. Since the ray-tracing simulation has the area of 25 square degree, we estimate the errors by multiplying the measured scatters among 1000 realizations with a factor . We set the binning width wider than the fundamental mode : the first 10 bins have linearly equal spacing as , while the remaining 25 bins have logarithmically equal spacing up to . Our reconstruction method successfully recovers the input -mode spectrum for both cases without intrinsic noise (left panels) and with noise (right panels). The top panel explicitly shows the ratio of the reconstructed -mode power spectra to the input spectrum. The accuracy of the reconstruction achieves a sub-percent level over the most ranges of multipoles.

The lower panels show the -mode power spectrum relative to the -mode spectrum. The mask and finite-sky effect generates -mode due to the mode mixing. In fact, there is a significant leakage of the -mode into the -mode (10% of E-mode power) as shown in triangle symbols. We find that the leakage disappears to be less than one percent after deconvolution (see the filled circle symbols).

Fig. 3 shows the results of the full-sky approach (Sec. 2.1) using 1000 Monte Carlo simulations of Gaussian shear fields. The error-bars represent statistical dispersion for a survey with 2000 square degree coverage. The binning width is set to be wider than : the first 10 bins have linearly equal spacing as with, while the remaining 20 bins have logarithmically equal spacing up to . The power at the lowest bin () is affected by the unseen modes larger than the surveyed region and thus the reconstructed power at the lowest bin varies with the chosen minimum and the binning width. When the minimum is taken to be slightly larger than , we find that the reconstructed power becomes almost equal to the input power. The accuracy is limited by the statistical errors due to insufficient sampling of such large-angle modes. The power spectrum without correcting for a finite-sky effect (dashed line) is smaller than the input power spectrum (solid line). The amplitude offset is roughly determined by the square of unmasked fraction times the survey area fraction, square degree divided by steradian, that is about .

Summarizing the results in Figs. 2 and 3 the pseudo-spectrum method recovers the input power spectrum at a sub-percent accuracy over a wide range of multipoles down to . As seen from the top panels, the ratio between the true and reconstructed spectra is close to unity over a range of multipoles we study. The scatters of the ratio from unity imply possible biases in the -mode power spectrum reconstruction at each multipole bin, and are smaller than the statistical errors of power spectrum measurement expected for a survey of 2000 sq. deg. coverage. The residual -mode power spectrum is suppressed below a percent level.

### 4.2 Correlated Spectrum Errors due to the Mode Mixing

Finite-sky effect makes the errors of the shear power spectra correlate between different bins. In this subsection we study this effect using the simulated maps.

Let’s start our discussion using Gaussian fields. The statistical errors of the binned power spectrum is given, in the absence of shot noise, as

(51) |

where is the sky fraction of survey area and is the number of modes available around the -th bin.

The left panel of Fig. 4 compares the Gaussian expectation (51) with the statistical errors in the -mode power spectrum of 1000 Gaussian shear fields. When the multipole bin width is taken as , 2.5 times wider than the the fundamental mode , the errors for the simulation results are greater than the Gaussian expectation. The limit of sky area and mask causes correlated errors between neighboring multipole bins and increases the errors by -% over a range of multipoles. When the bin width is enough wide such as , the power spectrum errors become similar to the Gaussian expectations, and the spectra at different bins become nearly independent.

The right panel of Fig. 4 compares the error of the reconstructed shear power relative to the unmasked convergence power using the ray-tracing simulations, which contain the non-Gaussian error due to nonlinear clustering in structure formation. At a bin width , a factor 3 wider than the fundamental mode , the power spectrum errors increase by about 5% on small multipoles, while the correlated errors are well suppressed at a wider binning . Note that the Gaussian errors depend on the bin width of multipoles, while the non-Gaussian errors do not: a wider bin relatively suppresses the Gaussian error contribution. As studied in Takada & Jain (2009) (also see Sato et al., 2009), the non-Gaussian error contribution is significant at multipoles for the CDM model.

Since most of useful cosmological information in the shear power spectrum resides in the modes around in the presence of the shot noise, Takada & Jain (2009) showed that even a factor 2 increase in the power spectrum errors at the multipoles degrades accuracies of cosmological parameters only by 10-20%. Therefore, the correlated errors due to the survey geometry effect have an insignificant impact on parameter estimation.

## 5 Summary and Discussion

We develop a pseudo-spectrum method for reconstructing the cosmic shear power spectra from actual lensing data. The observed shear field is limited to be a finite patch of sky and furthermore roughly 25% of the survey area is masked due to bright stars. We apply for the first time the pseudo-spectrum technique developed in CMB studies to the lensing field and show that our method successfully recovers the shear spectra over a wide range of multipoles from to in both full- and flat-sky approaches.

We test the flat-sky method using ray-tracing simulations assuming a square-shaped survey region. The 25% fraction of the total area is masked by realistic configurations for a ground-based survey: circular shapes for bright stars; rectangular shapes for bright star spikes; zero padding in one direction for bad pixels. We show that both the full- and flat-sky methods reconstruct the input -mode power spectrum in sub-percent accuracy and the residuals are much smaller than the statistical errors of a power spectrum measurement for a survey of 2000 square degree coverage. The residual -mode power spectrum from the -mode mixing due to the imperfect correction of survey geometry is also suppressed below a percent of the -mode power spectrum. Our method offers a new means of measuring the cosmic shear correlations and separating the modes from an actual survey data.

Although the pseudo-spectrum technique is promising, our method still yields sub-percent residual of -mode in the reconstructed power spectra. To further suppress the -mode spectrum, one has to remove “ambiguous mode” that is inevitably generated in a finite patch of sky (Bunn et al., 2003). The ambiguous mode satisfies both the -mode (rotation-free) and the -mode conditions (divergence-free) and thus contaminates E/B-mode spectrum reconstructed using the simple pseudo-spectrum method that we adopt. To eliminate such contamination, Bunn et al. (2003) introduces pure E/B modes that is orthogonal to the ambiguous modes. Pure pseudo estimator and its optimization technique of sky apodization have been developed (Smith, 2006; Smith & Zaldarriaga, 2007; Grain, Tristram & Stompor, 2009; Kim & Naselsky, 2010). This technique can be straightforwardly applied to the lensing case.

In this paper we assume that masked regions are uncorrelated with the cosmological shear field. In reality the regions with large shear is preferentially masked: in a region of massive clusters, we cannot obtain a fair sample of background galaxies in the central region due to the dense concentration of member galaxies, where the shearing effect on background galaxies are greater. Masking such a crowded region may bias the power spectrum measurement. This contaminating effect can be estimated by combining ray-tracing simulations with halo catalogs in the underlying N-body simulations. This is our future project, and will be presented elsewhere.

We deeply appreciate Masanori Sato for kindly providing ray-tracing simulation data. We also thank an anonymous referee for careful reading and providing useful comments. C.H. acknowledges support from a Japan Society for Promotion of Science (JSPS) fellowship. This work is in part supported in part by JSPS Core-to-Core Program “International Research Network for Dark Energy”, by Grant-in-Aid for Scientific Research from the JSPS Promotion of Science (18072001,21740202), by Grant-in-Aid for Scientific Research on Priority Areas No. 467 “Probing the Dark Energy through an Extremely Wide & Deep Survey with Subaru Telescope”, and by World Premier International Research Center Initiative (WPI Initiative), MEXT, Japan.

## References

- Bacon, Refregier & Ellis (2000) Bacon, D. J., Refregier, A. R., Ellis, R. S., 2000, MNRAS, 318, 625
- Bartelmann & Schneider (2001) Bartelmann, M., & Schneider, P., 2001, Phys. Rep., 340, 294
- Brown et al. (2003) Brown, M. L., Taylor, A. N., Bacon, D. J., Gray, M. E., Dye, S., Meisenheimer, K., Wolf, C., 2003, MNRAS, 341, 100
- Brown, Castro & Taylor (2005) Brown, M. L., Castro, P. G., Taylor, A. N., 2005, MNRAS, 360, 1262
- Bunn (2002) Bunn, E. F., 2002, Phys. Rev. D, 65, 043003
- Bunn et al. (2003) Bunn, E. F., Zaldarriaga, M., Tegmark, M., de Oliveira-Costa A., 2003, Phys. Rev. D, 67, 023501
- Cooray & Hu (2001) Cooray, A., Hu, W., 2001, ApJ, 554, 56
- Crittenden et al. (2002) Crittenden, R. G., Natarajan, P., Pen, U.-L., Theuns, T., 2002, ApJ, 568, 20
- Dahlen & Tromp (1998) Dahlen, F. A., Tromp, J., 1998, Theoretical Global Seismology. Princeton Univ. Press, Princeton, NJ
- Fu et al. (2008) Fu, L., et al., 2008, A&A, 479, 9
- Grski et al. (2005) Grski, K. M. et al., 2005, ApJ, 622, 759
- Grain, Tristram & Stompor (2009) Grain, J., Tristram, M., Stompor, R., 2009, Phys. Rev. D, 79, 123515
- Hamana & Mellier (2001) Hamana, T., Mellier, Y. 2001, MNRAS, 327, 169
- Hamana et al. (2003) Hamana, T., et al., 2003, ApJ, 597, 98
- Hoekstra & Jain (2008) Hoekstra, H., Jain, B., 2008, Ann. Rev. Nucl. Part. Sci., 58, 99
- Hu & White (2001) Hu, W., White, M., 2001, ApJ, 554, 67
- Ichiki, Takada & Takahashi (2009) Ichiki, K., Takada, M., Takahashi, T., 2009, Phys. Rev. D, 79, 023520
- Jain, Seljak & White (2000) Jain, B., Seljak, U., White, S., 2000, ApJ, 530, 547
- Joachimi, Schneider & Efler (2008) Joachimi, B., Schneider, P., Efler, T., 2008, A&A, 477, 43
- Kaiser, Wilson & Luppino (2000) Kaiser, N., Wilson, G., Luppino, G. A., 2000, preprint (arXiv:astro-ph/0003338)
- Kim & Naselsky (2010) Kim, J., Naselsky, P., 2010, preprint (arXiv:1003.2911)
- Kogut et al. (2003) Kogut, A., et al., 2003, ApJS, 148, 161
- Limber (1954) Limber, D. N., 1954, ApJL, 119, 655
- Miyazaki et al. (2006) Miyazaki, S., et al., 2006, SPIE, 6269, 9
- Pielorz et al. (2009) Pielorz, J., Rödiger, J., Tereno, I., Schneider, P., 2009, preprint (arXiv:0907.1524)
- Refregier et al. (2010) Refregier, A., et al. 2010, preprint (arXiv:1001.0061)
- Sato et al. (2009) Sato, M., Hamana, T., Takahashi, R., Takada, M., Yoshida, N., Matsubara, T., Sugiyama, N., 2009, ApJ, 701, 945
- Schneider et al. (1998) Schneider, P., Van Waerbeke, L., Jain, B., Kruse, G., 1998, MNRAS, 296, 873
- Schneider et al. (2002) Schneider, P., Van Waerbeke, L., Kilbinger, M., Mellier, Y., 2002, A&A, 396, 1
- Schneider, Eifler & Krause (2010) Schneider, P., Eifler, T., Krause, E., 2010, preprint (arXiv:1002.2136)
- Schrabback et al. (2010) Schrabback, T., et al., 2010, A&A, 516, 63
- Seljak (1998) Seljak, U., 1998, ApJ, 506, 64
- Semboloni et al. (2007) Semboloni, E., et al., 2007, MNRAS, 375, L6
- Smith (2006) Smith, K. M., 2006, Phys. Rev. D, 74, 083002
- Smith & Zaldarriaga (2007) Smith, K. M., Zaldarriaga, M., 2007, Phys. Rev. D, 76, 043001
- Spergel et al. (2007) Spergel, D. N., et al., 2007, ApJS, 170, 377
- Springel (2005) Springel, V., 2005, MNRAS, 364, 1105
- Takada & Bridle (2007) Takada, M., Bridle, S., 2007, New J. Phys., 9, 446
- Takada & Jain (2009) Takada, M., Jain, B., 2009, MNRAS, 395, 2065
- Van Waerbeke et al. (2000) Van Waerbeke, L., et al. 2000, A&A, 358, 30
- Wandelt, Hivon & Gorski (2001) Wandelt, B. D., Hivon, E., Gorski, K. M., 2001, Phys. Rev. D, 64, 083003
- Wittman et al. (2000) Wittman, D. M., Tyson, J. A., Kirkman, D., Dell’Antonio, I., Bernstein, G., 2000, Nature, 405, 143
