Research Paper Volume 13, Issue 24 pp 25778—25798

PKMYT1, exacerbating the progression of clear cell renal cell carcinoma, is implied as a biomarker for the diagnosis and prognosis


Figure 7. Functional enrichment analysis. Gene set enrichment analysis showed that high PKMYT1 expression was associated with the biological process of epithelial–mesenchymal transition (A) and G2M checkpoint (B). (C) The modules were identified by weighted gene co-expression network analysis. (D) Correlations between modules. The results of enriched terms for genes in the green module, including biological process (E), cellular component (F) molecular function (G) and KEGG (H).
