Research Paper Volume 12, Issue 20 pp 20413—20431

Systemic analyses of expression patterns and clinical features for GIMAPs family members in lung adenocarcinoma

Figure 5. Representative immunohistochemistry images of distinct GIMAPs in LUAD tissues and normal lung tissues (Human Protein Atlas). GIMAP1/2 proteins were low expressed in normal lung tissues, whereas not expressions of them were observed in LUAD tissue (A, B). In addition, medium protein expressions of GIMAP4/6 were expressed in normal lung tissues, while not and low protein expressions of them were observed in LUAD tissue (C, D). Moreover, GIMAP7/8 would have high protein expressions in normal lung tissues compared with the LUAD tissue have not and low protein expressions (E, F).
